Appication Scopes | |
Medium | Gas, oil, water, noncrystalline acids, bases, salts, organic solvents, etc. |
Pressure | <1MPa |
Temperature | -50-220°C |
Shaft diameter | 18-200MM |
Linear Velocity | <15m/s |
Viscosity | ≤300CP |
Structural Features
1. Multi spring, sleeve drive, double face seal. When used, it has nothing to do with the direction of rotation. The spring seat, spring and push ring can be assembled in advance, and the installation is convenient.
2. In addition to the installation length of the drive seat, the other installation dimensions (d≤100mm) are in line with DIN24960 standard, versatility is strong.
